HCPL-0600-500E Broadcom Limited HCPL-0600-500E Real Image HCPL-0600-500E label picture HCPL-0600-500E real image 2 HCPL-0600-500E real image4542 HCPL-0600-500E real image4543 HCPL-0600-500E Real Image1 HCPL-0600-500E Real Image2 HCPL-0600-500E Real Image3
Same model may have multiple batches, images only for reference.
HCPL-0600-500E Broadcom Limited HCPL-0600-500E Real Image HCPL-0600-500E label picture HCPL-0600-500E real image 2 HCPL-0600-500E real image4542 HCPL-0600-500E real image4543 HCPL-0600-500E Real Image1 HCPL-0600-500E Real Image2 HCPL-0600-500E Real Image3
HCPL-0600-500E Broadcom Limited HCPL-0600-500E Real Image HCPL-0600-500E label picture HCPL-0600-500E real image 2 HCPL-0600-500E real image4542 HCPL-0600-500E real image4543 HCPL-0600-500E Real Image1 HCPL-0600-500E Real Image2 HCPL-0600-500E Real Image3
Same model may have multiple batches, images only for reference.

HCPL-0600-500E

Part No HCPL-0600-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPN COLLECTOR 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 5kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 50mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Max) 100ns, 100ns
Rise and Fall Time 24ns, 10ns
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO Tall
Win Source Part Number 016832-HCPL-0600-500E
Family Name HCPL-0600
Introduction Date November 01, 2004
ECCN EAR99
Country of Origin Philippines, Singapore
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing, Computers & Computer Peripherals, Power Management, Industrial
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian HCPL-0600-500E CAD Model

Description

The Broadcom Limited electronic component with Win Source Part Number 016832-HCPL-0600-500E is a high popularity item with a sufficient supply and demand status. The product is an isolator.

  • Output Type: Open Collector, Schottky Clamped
  • Data Rate: 10MBd
  • Forward Voltage: 1.5V
  • Common Mode Transient Immunity: 5kV/μs
  • Propagation Delay tpLH/tpHL (max): 100ns, 100ns
  • Isolation Voltage: 3750Vrms
  • Family: HCPL-0600
  • Category: Isolator
  • Package Type: 8-SO Tall
  • EOL Date (Estimated): 2024
  • Halogen-Free: Compliant
  • Quantity per Package: 1,500
  • Applications: Signal Processing, Computers and Computer Peripherals, Power Management, and Industrial
