The HCPL-0453-500E is a high-speed optocoupler with transistor output from Broadcom Limited. It has a maximum isolation voltage of 3750Vrms and a minimum DC current transfer ratio of 15% at 16mA.

• Output Type: Transistor
• Isolation Voltage: 3750Vrms
• DC Current Transfer Ratio (Minimum): 15% @ 16mA
• Channel(s): 1
• Forward Voltage: 1.5V
• Output Voltage (Maximum): 20V
• Package: 8-SO
• Switching Turn-On Time: 1μs (Max)
• Switching Turn-Off Time: 1μs (Max)
• Operating Temperature: -55°C to 100°C
• Continuous Forward Current: 25mA
• Channel Output Current: 8mA
• Popularity: High
• Supply and Demand: Balanced
• Halogen-Free: Yes
• Estimated EOL Date: 2026
