ACPL-M50L-000E Real Image ACPL-M50L-000E real image15011
Same model may have multiple batches, images only for reference.
ACPL-M50L-000E Real Image ACPL-M50L-000E real image15011
ACPL-M50L-000E Real Image ACPL-M50L-000E real image15011
Same model may have multiple batches, images only for reference.

ACPL-M50L-000E

Part No ACPL-M50L-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 3.75KV TRANS 5-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 100% @ 3mA
Maximum DC Current Transfer Ratio 200% @ 3mA
Switching Turn-On and Turn-Off Time 200ns, 380ns
Input Type DC
Output Type Transistor
Maximum Output Voltage 24V
Channel Output Current 8mA
Forward Voltage 1.5V
Continuous forward current- Max 20mA
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 5-SO
Win Source Part Number 1011758-ACPL-M50L-000E
Popularity Medium
Supply and Demand Status Limited
Quantity per package 100
Ultra Librarian 3D Model Ultra Librarian ACPL-M50L-000E CAD Model

Description

The Broadcom Limited ACPL-M50L-000E is an isolator with a minimum DC current transfer ratio of 100% @ 3mA and a maximum DC current transfer ratio of 200% @ 3mA.

  • Switching Turn-On Time: 200ns
  • Switching Turn-Off Time: 380ns
  • Isolation Voltage: 3750Vrms
  • Input Type: DC compatible
  • Package: 5-SO
  • Forward Voltage: 1.5V
  • Channel Output Current: 8mA
