ASMT-M015 Broadcom Limited – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ASMT-M015

Part No ASMT-M015
Manufacturer Broadcom Limited
Catalog Optics - Lenses
Description LENS CLEAR 15DEG PRESS FIT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Lens Only, Holder Required
Color Clear
Number of LEDs 1
Lens Style Round with Flat Top
Lens Size 20mm Dia
Lens Transparency Clear
Viewing Angle 15°
For Use With/Related Manufacturer Avago
Material Acrylic
Mounting Type Press Fit
Package Tray
Supply and Demand Status Limited
Win Source Part Number 1569791-ASMT-M015
Ultra Librarian 3D Model Ultra Librarian ASMT-M015 CAD Model

Description

N
