ACPL-337J-500E Real Image ACPL-337J-500E Real Image
Same model may have multiple batches, images only for reference.
ACPL-337J-500E Real Image ACPL-337J-500E Real Image
ACPL-337J-500E Real Image ACPL-337J-500E Real Image
Same model may have multiple batches, images only for reference.

ACPL-337J-500E

Part No ACPL-337J-500E
Manufacturer Broadcom Limited
Catalog Isolators - Gate Drivers
Description OPTOISO 5KV 1CH GATE DRIVER 16SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel
Technology Optical Coupling
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Minimum) 30kV/μs
Propagation Delay tpLH / tpHL (Maximum) 220ns, 250ns
Pulse Width Distortion (Maximum) 120ns
Rise / Fall Time 80ns, 45ns
Current - Output High, Low 3A, 3A
Current - Peak Output 4A
Voltage - Forward (Vf) 1.55V
Current - DC Forward (If) (Maximum) 20mA
Voltage - Output Supply 15V ~ 30V
Temperature Range - Operating -40°C ~ 105°C
Mounting Style SMD
Manufacturer Package 16-SOIC
Supplier Device Package 16-SO
Approvals CSA, IEC/EN/DIN, UR
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 751679-ACPL-337J-500E
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ACPL-337J-500E CAD Model

Description

The ACPL-337J-500E is an optical coupling isolator made by Broadcom Limited.

  • Mounting: Reel
  • Approvals: CSA, IEC/EN/DIN, UR
  • Current output (high/low): 3A
  • Voltage isolation: 5000Vrms
  • Current peak output: 4A
  • Supplier device package: 16-SO
  • Operating temperature: -40°C to 105°C
  • Manufacturer package: 16-SOIC
  • Current DC forward (If) (maximum): 20mA
  • Common mode transient immunity (minimum): 30kV/μs
  • Propagation delay tpLH/tpHL (maximum): 220ns, 250ns
  • Pulse width distortion (maximum): 120ns
  • Supply and demand status: Limited
  • Manufacturer pack quantity: 1
  • MSL level: 1 (Unlimited)
  • Rise/fall time: 80ns, 45ns
  • Forward voltage: 1.55V
  • Voltage output supply: 15V to 30V
