ACNW261L-000E Real Image ACNW261L-000E Real Image
Same model may have multiple batches, images only for reference.
ACNW261L-000E Real Image ACNW261L-000E Real Image
ACNW261L-000E Real Image ACNW261L-000E Real Image
Same model may have multiple batches, images only for reference.

ACNW261L-000E

Part No ACNW261L-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV TRI-STATE 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Minimum) 20kV/μs
Input Type DC
Output Type Tri-State
Output Current per Channel 10mA
Data Rate 10MBd
Propagation Delay tpLH / tpHL (Maximum) 95ns, 95ns
Rise / Fall Time (Typ) 12ns, 12ns
Voltage - Forward (Vf) (Typ) 1.5V
Current - DC Forward (If) (Maximum) 8mA
Operating Supply Voltage 2.7 V ~ 5.5 V
Operating Temperature Range -40°C ~ 105°C
Mounting Style Through Hole
Package 8-DIP (0.354", 9.00mm)
Manufacturer Package 8-DIP
Win Source Part Number 766924-ACNW261L-000E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 42
Family Name ACNW261L
Introduction Date April 02, 2012
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian ACNW261L-000E CAD Model

Description

The Broadcom Limited 766924-ACNW261L-000E is an isolator that has a data rate of 10MBd.

  • Data Rate: 10MBd
  • Popularity: Medium
  • Supply and Demand: Balanced
  • Packaging: Tube
  • Quantity: 42
  • Operating Temperature: -40°C ~ 105°C
  • Voltage - Isolation: 5000Vrms
  • ECCN: EAR99
  • Estimated EOL Date: 2028
  • Introduction Date: April 02, 2012
