SMBJ54CA Real Image SMBJ54CA real image5604
Same model may have multiple batches, images only for reference.
SMBJ54CA Real Image SMBJ54CA real image5604
SMBJ54CA Real Image SMBJ54CA real image5604
Same model may have multiple batches, images only for reference.

SMBJ54CA

Part No SMBJ54CA
Manufacturer Bourns Inc.
Catalog TVS - Diodes
Description TVS DIODE 54VWM 87.1VC DO214AA
Datasheet
SMBJ54CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection
Family TVS - Diodes
Manufacturer Bourns Inc.
Series SMBJ
Packaging Reel(TR)
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 54V
Voltage - Breakdown (Min) 60V
Voltage - Clamping (Max) @ Ipp 87.1V
Current - Peak Pulse (10/1000μs) 6.9A
Power - Peak Pulse 600W
Power Line Protection No
Applications General Purpose
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style SMD/SMT
Package DO-214AA, SMB
Manufacturer Device Package SMB (DO-214AA)
Win Source Part Number 029247-SMBJ54CA
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SMBJ54CA CAD Model

Description

The SMBJ54CA is a Zener diode manufactured by Bourns Inc.

  • Manufacturer: Bourns Inc.
  • Series: SMBJ
  • Type: TVS diodes
  • Application: circuit protection
  • Voltage Rating: 54V
  • Breakdown Voltage: 60V
  • Clamping Voltage: 87.1V @ peak pulse current of 6.9A
  • Package: DO-214AA SMB
  • Compliance: RoHS compliant
  • Reliability: efficient choice for any application requiring circuit protection against voltage spikes and surges
