LC72AY-1 Real Image
Same model may have multiple batches, images only for reference.

LC72AY-1

Part No LC72AY-1
Manufacturer Bourns Inc.
Catalog Temperature Sensors - Thermostats - Mechanical
Description THERMOSTAT 72DEG C NC STRAP SLDR / Komatsulite™ LC Series Breaker
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Bourns Inc.
Circuit SPST-NC
Switching Temperature 162°F (72°C)
Reset Temperature 104°F (40°C)
Current Rating - DC 12A (9V)
Tolerance ±9°F (±5°C)
Switching Cycles 6K
Termination Style Solder Pad
Mounting Style Weld Tab
Manufacturer Package Strap
Part Number Series LC72AY
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Popularity High
Supply and Demand Status Sufficient
Win Source Part Number 801195-LC72AY-1
Ultra Librarian 3D Model Ultra Librarian LC72AY-1 CAD Model

Description

The Bourns Inc. LC72AY-1 is a snap-action thermal protector switch with a normally closed circuit.

  • Switching Temperature: 162°F (72°C)
  • Reset Temperature: 104°F (40°C)
  • Switching Cycles: 6K
  • Current Rating: 12A (9V) DC
  • Termination: Solder pad, weld tab
  • Tolerance: ±9°F (±5°C)
  • Supply and Demand Status: Sufficient
