HC77AY-1 Real Image
Same model may have multiple batches, images only for reference.

HC77AY-1

Part No HC77AY-1
Manufacturer Bourns Inc.
Catalog Fuses
Description THERMOSTAT 77DEG C NC STRAP SLDR
Datasheet
HC77AY-1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Thermal Cutoffs (Thermal Fuses)
Mfr Bourns Inc.
Series Komatsulite™, HC
Package Bag
Product Status Active
Type Breaker
Rated Functioning Temperature 77°C (171°F)
Reset Temperature 40°C (104°F)
Voltage Rating - DC 28
Current Rating (Amps) 25 A
Approval Agency cUL, TUV, UL
Package / Case Nonstandard
Base Product Number HC77AY
Standard Package 5,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.20.0020
California Prop 65 Warning Information
Win Source Part Number 873240-HC77AY-1
Ultra Librarian 3D Model Ultra Librarian HC77AY-1 CAD Model

Description

The Komatsulite™ HC thermal cutoff is a circuit protection device used to prevent overheating and potential fire hazards in electronic circuits.

  • Voltage Rating: 28V DC
  • Current Rating: 25A
  • Reset Temperature: 40°C (104°F)
  • Rated Functioning Temperature: 77°C (171°F)
  • Type: Breaker
  • Package: Bag
  • Applications: Power supplies, battery packs, and consumer electronics
  • Certifications: cUL, TUV, and UL
