SDE0403A-220M Real Image
Same model may have multiple batches, images only for reference.

SDE0403A-220M

Part No SDE0403A-220M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SDE0403A-220M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SDE0403A
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 22 µH
Tolerance ±20%
Current Rating (Amps) 700 mA
Current - Saturation (Isat) 950mA
Shielding Unshielded
DC Resistance (DCR) 351mOhm Max
Frequency - Self Resonant 25MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 1 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max) 0.138" (3.50mm)
Base Product Number SDE0403A
Other Names SDE0403A-220MCT,SDE0403A-220MTR,SDE0403A-220MDKR
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1274934-SDE0403A-220M
Ultra Librarian 3D Model Ultra Librarian SDE0403A-220M CAD Model

Description

The Bourns SDE0403A is a series of unshielded, fixed inductors designed for SMD (SMT) mounting.

  • Model: SDE0403A-220M
  • Core Type: Drum Core
  • Type: Wirewound
  • Inductance: 22 μH
  • Tolerance: ±20%
  • Material: Ferrite
  • Height: 0.138" (3.50mm)
  • Packaging: Tape & Reel
  • Units per Package: 2,000
  • Temperature Range: -40°C to 125°C
  • AEC-Q200: Rated
  • Current Rating: 700 mA
  • Applications: Various electronic devices
