AEE01AA24 Artesyn Embedded Technologies
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Artesyn Embedded Technologies
Packaging Bulk
Status Obsolete
Type Isolated Module
Number of Outputs 2
Voltage - Input (Minimum) 18V
Voltage - Input (Maximum) 36V
Voltage - Output 1 5V
Voltage - Output 2 -5V
Current - Output (Maximum) 1A, 1A
Power (W) 10W
Voltage - Isolation 500V
Applications ITE (Commercial)
Temperature Range - Operating -25°C ~ 95°C
Efficiency 79%
Mounting Style Through Hole
Manufacturer Package 5-DIP Module
Parts Dimension 2.00" L x 1.00" W x 0.33" H (50.8mm x 25.4mm x 8.5mm)
Manufacturer Pack Quantity 10
MSL Level 1 (Unlimited)
Win Source Part Number 1142802-AEE01AA24
Manufacturer Homepage www.astecinc.com/
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian AEE01AA24 CAD Model

Description

The Artesyn Embedded Technologies isolated module power supply is designed for ITE (Commercial) applications.

  • Application: ITE (Commercial)
  • Voltage Isolation: 500V
  • Outputs: 5V and -5V
  • Efficiency: 79%
  • Mounting: Through Hole
  • Temperature Range: -25°C to 95°C
  • Status: Obsolete
  • Supply and Demand: Limited
  • Package: 5-DIP Module
  • Dimensions: 2.00" L x 1.00" W x 0.33" H (50.8mm x 25.4mm x 8.5mm)
  • Maximum Output Power: 10W
