ADXL337BCPZ

Part No ADXL337BCPZ
Manufacturer Analog Devices Inc.
Catalog Motion Sensors - Accelerometers
Description ACCELEROMETER 3G ANALOG 16LFCSP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Motion Sensors - Accelerometers
Mfr Analog Devices Inc.
Package Tray
Product Status Obsolete
Standard Package 490 pcs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN OBSOLETE
Win Source Part Number 709419-ADXL337BCPZ
Ultra Librarian 3D Model Ultra Librarian ADXL337BCPZ CAD Model

Description

ADXL337BCPZ - Accelerometer by Analog Devices Inc.

The ADXL337BCPZ is a small, thin, low power, complete 3-axis accelerometer with signal conditioned voltage outputs, all on a single monolithic IC. Manufactured by Analog Devices Inc., a leader in precision signal processing solutions, this product is designed to measure acceleration with a full-scale range of ±3g. It can measure the static acceleration of gravity in tilt-sensing applications, as well as dynamic acceleration resulting from motion, shock, or vibration.

The device comes in a compact 3mm x 3mm x 0.9mm, 16-lead, plastic lead frame chip scale package (LFCSP_LQ). This small form factor and low power consumption make the ADXL337BCPZ an excellent choice for mobile applications and other space-constrained systems.

Key features of the ADXL337BCPZ include:

  • 3-axis sensing: Provides simultaneous X, Y, and Z-axis acceleration sensing.
  • Low power consumption: Ideal for battery-powered devices, it supports a wide voltage range from 1.8V to 3.6V.
  • Analog output: Each axis has its own analog output which can be interfaced with analog inputs on microcontrollers or analog-to-digital converters.
  • High sensitivity: Offers high resolution (1 mg/LSB) which allows for the measurement of inclination changes less than 1.0°.
  • Temperature stability: Maintains consistent performance across a temperature range of -40°C to +85°C.
  • Shock resistance: Robust design that can survive up to 10,000g shock events.

Applications for the ADXL337BCPZ are diverse and include:

  • Mobile devices (phones, gaming controllers)
  • Sports and health devices (activity monitors, pedometers)
  • Industrial systems (machinery monitoring, vibration analysis)
  • Consumer electronics (pointing devices, toys)
  • Vehicle dynamics
  • Tilt sensing in robotics and remote controls

The ADXL337BCPZ is a versatile and reliable accelerometer, providing precise measurements for a variety of applications. With its easy-to-use analog interface and low power consumption, it offers a convenient solution for adding motion and orientation detection to your projects or products.
