ADSP-CM409CBCZ-AF

Part No ADSP-CM409CBCZ-AF
Manufacturer Analog Devices Inc.
Catalog Embedded - DSP (Digital Signal Processors)
Description IC ARM CORTEX M4 FLASH 212CSBGA
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Embedded - DSP (Digital Signal Processors)
Mfr Analog Devices Inc.
Series -
Package Bulk
Product Status Active
Type Floating Point
Interface CAN, Ethernet, I²C, SPI, SPORT, UART/USART, USB
Clock Rate 240MHz
Non-Volatile Memory FLASH (2MB)
On-Chip RAM 384kB
Voltage - I/O 3.30V
Voltage - Core 1.20V
Temperature Range - Operating -40°C ~ 105°C (TA)
Mounting Type Surface Mount
Package / Case 212-LBGA, CSPBGA
Supplier Device Package 212-CSPBGA (19x19)
Base Product Number ADSP-CM409
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Win Source Part Number 1368553-ADSP-CM409CBCZ-AF
Ultra Librarian 3D Model Ultra Librarian ADSP-CM409CBCZ-AF CAD Model

Description

The ADSP-CM409CBCZ-AF is a high-performance, mixed-signal control processor from the reputable Analog Devices Inc. This processor is part of the ADSP-CM40x series, which is specifically designed to cater to the demanding needs of industrial, automotive, and general-purpose applications requiring efficient signal processing capabilities combined with robust control functionalities.

Key Features

  • Core: The device features an ARM Cortex-M4 core, which includes a floating-point unit (FPU) for efficient computation of complex algorithms. The core operates at a frequency that provides a perfect balance between processing power and energy efficiency.
  • Memory: Equipped with ample memory, the ADSP-CM409CBCZ-AF includes integrated flash memory and SRAM, facilitating advanced applications and algorithms without the need for external memory components.
  • Analog Integration: The processor boasts a rich set of analog peripherals, including multi-channel, 16-bit analog-to-digital converters (ADCs) and digital-to-analog converters (DACs), which allow for high-precision signal acquisition and control.
  • Connectivity: With a variety of communication interfaces such as UART, SPI, I2C, and CAN, this processor ensures seamless integration with a broad range of external devices and systems.
  • Package: The ADSP-CM409CBCZ-AF comes in a compact 121-ball CSPBGA package, which is ideal for space-constrained applications.

Applications

The processor's combination of processing power, memory, and analog features makes it suitable for a wide array of applications. These include motor control, industrial automation, sensor fusion, power management, and automotive systems. Its robust design ensures reliable operation even in harsh environments.

Quality and Reliability

Analog Devices Inc. is known for its commitment to quality, and the ADSP-CM409CBCZ-AF is no exception. It is built to meet high standards of reliability and performance, making it a trusted choice for engineers and designers looking for a processor that can deliver consistent results over the long term.

For detailed specifications, application notes, and further information, interested parties are encouraged to visit the Analog Devices Inc. website or contact their local sales representative.
