The ADM3050EBRIZ is a high-performance, isolated Controller Area Network (CAN) transceiver that serves as an interface between a CAN protocol controller and the physical two-wire CAN bus. Designed and manufactured by Analog Devices Inc., this transceiver is engineered to provide reliable communication in noisy environments, typical for industrial and automotive applications.

Key Features

• Isolation: The device boasts integrated isolation with a withstand voltage rating of 2500 Vrms for 1 minute, providing robust protection against high voltage transients and enhancing system reliability.
• High Speed: It supports the CAN FD (Flexible Data-rate) for higher bandwidth with data rates up to 12 Mbps, making it suitable for modern high-speed CAN networks.
• Low Emissions: The ADM3050EBRIZ is designed with low electromagnetic emissions and high immunity to electromagnetic interference, ensuring compliance with stringent EMC requirements.
• Extended Temperature Range: It operates over a wide industrial temperature range from -40°C to +125°C, suitable for harsh environmental conditions.
• Bus Protection: The device includes features such as bus fault protection to ±30 V and over-temperature shutdown, adding an extra layer of safety for the connected systems.
• Compact Package: Housed in a small, surface-mount LGA package, the ADM3050EBRIZ saves valuable board space and is ideal for space-constrained applications.

Applications

The ADM3050EBRIZ is versatile and can be used in a wide array of applications, including:

• Industrial automation and control systems
• Automotive networks
• Building automation
• Medical equipment and instrumentation

Conclusion

With its robust design and advanced features, the ADM3050EBRIZ from Analog Devices Inc. stands out as a reliable solution for any application requiring isolated CAN communication. Its ability to withstand harsh environments, protect against voltage transients, and minimize electromagnetic interference makes it an excellent choice for designers looking to enhance the performance and integrity of their CAN networks.
