ADIS16354AMLZ

Part No ADIS16354AMLZ
Manufacturer Analog Devices Inc.
Catalog Motion Sensors - IMU (Inertial Measurement Units)
Description MODULE GYRO/ACCELEROMETER 24LD
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Motion Sensors - IMUs (Inertial Measurement Units)
Mfr Analog Devices Inc.
Series iMEMS®, iSensor™
Package Box
Product Status Obsolete
Sensor Type Accelerometer, Gyroscope, 6 Axis
Output Type SPI
Package / Case Module
Supplier Device Package Module
Mounting Type Chassis Mount
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN 7A994
HTSUS 8543.70.9860
Win Source Part Number 910426-ADIS16354AMLZ
Ultra Librarian 3D Model Ultra Librarian ADIS16354AMLZ CAD Model

Description

ADIS16354AMLZ Inertial Measurement Unit by Analog Devices Inc.

The ADIS16354AMLZ is a high-performance, precision inertial measurement unit (IMU) designed by Analog Devices Inc., a leader in the field of high-performance semiconductors. This compact, six-degrees-of-freedom sensor combines three-axis gyroscope and three-axis accelerometer data to deliver reliable and accurate motion tracking and navigation information, making it an ideal solution for a wide range of applications including robotics, vehicle navigation, platform stabilization, and motion analysis.

Key Features

  • Tri-Axis Gyroscope: With a full-scale range of ±300°/sec, the gyroscope provides precise angular rate detection, enabling smooth and accurate tracking of rotational movements.
  • Tri-Axis Accelerometer: The accelerometer offers a full-scale range of ±5g, allowing for the capture of linear acceleration data, crucial for navigation and motion analysis.
  • Calibration: Factory-calibrated for sensitivity, bias, alignment, and scale factor, the ADIS16354AMLZ ensures high accuracy and consistency of measurements right out of the box.
  • Data Integrity: Featuring a 16-bit analog-to-digital converter (ADC) for each sensor axis, the IMU delivers high-resolution data with low noise characteristics.
  • Signal Conditioning: Built-in signal conditioning, such as filtering and scaling, enhances the quality of the output data, making it ready for use in various systems without the need for additional processing.
  • Temperature Sensing: The onboard temperature sensor helps in compensating for temperature-related drifts, ensuring stable performance across a wide operating temperature range.
  • Robust Design: Encased in a durable module, the ADIS16354AMLZ is designed to withstand harsh environments and is suitable for both prototyping and high-volume production.

Applications

  • Robotics and automation
  • Vehicle navigation and control systems
  • Platform stabilization for cameras and antennas
  • Flight control systems for UAVs and manned aircraft
  • Sports and health monitoring devices

The ADIS16354AMLZ from Analog Devices Inc. is a testament to the company's commitment to providing advanced sensing technology that meets the demanding requirements of modern applications. Its combination of performance, reliability, and ease of integration makes it an excellent choice for designers and engineers looking to enhance the capabilities of their systems with state-of-the-art motion tracking and analysis.
