The ADG819BRT from Analog Devices Inc. is a high-performance, CMOS analog switch that offers a superior solution for precision signal routing in a variety of applications. This device is part of the renowned ADG819 series, which is known for its reliability and efficiency in managing analog signals.

Key Features

• Dual Single-Pole, Double-Throw (SPDT) Switch: The ADG819BRT features two independently controllable SPDT switches, providing versatility in signal routing within a single compact package.
• Low On-Resistance: The switch offers an exceptionally low on-resistance (typically 0.4 ohms), which ensures minimal signal distortion and power loss across the switch.
• Single Supply Operation: Designed for single-supply operation, the ADG819BRT can operate from a single 1.8V to 5.5V power source, making it suitable for battery-powered and portable devices.
• Fast Switching Times: The device boasts fast switching times (t<sub>ON of 4 ns and t<sub>OFF of 2 ns), which makes it ideal for high-speed applications.
• Low Power Consumption: With ultralow power dissipation, the ADG819BRT is optimized for power-sensitive designs.
• Wide Operating Temperature Range: The device is operational over an extended temperature range of -40°C to +125°C, ensuring reliable performance in harsh environments.

Applications

The ADG819BRT is suitable for a wide array of applications, including but not limited to:

• Audio and video signal routing
• Communication systems
• Data acquisition systems
• Test equipment and instrumentation
• Relay replacement

Package and Quality

Encased in a compact SOT-23-6 package, the ADG819BRT is designed for space-constrained applications. The device is also RoHS compliant and adheres to the stringent quality standards set by Analog Devices Inc., ensuring both environmental friendliness and exceptional performance.
