The ADG5413BRUZ-REEL7 is a robust, high-performance quad SPST switch manufactured by Analog Devices Inc., a company renowned for its precision engineering and cutting-edge technology in the field of semiconductor design. This component is part of the ADG5413 series and is packaged in a convenient tape and reel format, denoted by the suffix 'REEL7', which facilitates automated assembly processes for high-volume production requirements.

Key Features

• Switch Configuration: Quad Single Pole Single Throw (SPST)
• Supply Voltage Range: ±15 V to ±22 V, 30 V single supply
• On Resistance (Max): 10 Ω
• On Time (Max): 150 ns
• Off Time (Max): 100 ns
• Operating Temperature Range: -40°C to +125°C
• Package: TSSOP-16

The ADG5413BRUZ-REEL7 features four independently controllable single-pole, single-throw (SPST) switches. This configuration offers flexibility for various applications, including signal routing and multiplexing. With a wide supply voltage range, it accommodates a broad spectrum of power requirements, making it suitable for both dual and single supply operations.

One of the standout characteristics of this product is its low on resistance, which ensures minimal signal distortion and power loss when the switch is in the 'on' state. Additionally, the rapid switching times of the ADG5413BRUZ-REEL7, with maximum on and off times of 150 ns and 100 ns respectively, make it an excellent choice for applications that require fast switching performance.

The device's extended operating temperature range makes it reliable for use in harsh environments, ensuring consistent performance across various conditions. The TSSOP-16 packaging is compact and surface-mountable, which helps to conserve space on printed circuit boards.

Overall, the ADG5413BRUZ-REEL7 by Analog Devices Inc. is an exceptional choice for designers looking for a high-quality, versatile switching solution that can perform reliably in a wide range of applications, from industrial and instrumentation to consumer electronics.
