Product Overview: AD7658BSTZ-1

The AD7658BSTZ-1 is a cutting-edge data acquisition system from Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This particular model is part of the AD7658 series, which are 16-bit, 8-channel, charge redistribution successive approximation register (SAR) analog-to-digital converters (ADCs). It is designed to deliver high precision and speed for a wide range of applications, including industrial automation, medical instrumentation, and data acquisition systems.

Encased in a 64-lead LQFP (Low Profile Quad Flat Package), the AD7658BSTZ-1 operates on a 5V analog supply and a 1.8V to 5V digital supply, providing flexibility for interfacing with different digital logic levels. The device features a maximum sample rate of 250 kSPS (kilo-samples per second), allowing for high-speed data processing and accurate real-time measurements.

Key Features:

• Multi-Channel Flexibility: The device includes eight single-ended inputs or four differential inputs, giving users the option to configure the input channels based on their specific requirements.
• High Precision: With its 16-bit resolution and low noise performance, the AD7658BSTZ-1 ensures precise data conversion, essential for critical measurement tasks.
• Integrated Features: The ADC includes an internal 2.5V reference and reference buffer, on-chip temperature sensor, and a power-down mode to reduce power consumption when not in active use.
• Interface Compatibility: The device features a parallel interface that is compatible with most microcontrollers and digital signal processors (DSPs), making system integration straightforward.
• Robust Operation: The ADC is specified for operation over the industrial temperature range of -40°C to +85°C, ensuring reliable performance under varying environmental conditions.

Applications:

The AD7658BSTZ-1 is adept at serving a broad spectrum of applications. It is particularly well-suited for:

• Industrial Control Systems
• Medical Instrumentation
• Data Acquisition Systems
• Instrumentation and Control Systems
• Multi-channel Data Logging

With its blend of speed, precision, and versatility, the AD7658BSTZ-1 from Analog Devices Inc. is an ideal choice for professionals seeking a reliable ADC solution to meet the demands of complex and sensitive applications.
