Products specifications Report Issue?

Win Source Part Number 3000001143-APDB-00
Manufacturer ams-OSRAM USA INC.
Category Optoelectronics -LED Emitters - Infrared, UV, Visible
Package Tray
Type Infrared (IR)
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount
Operating Temperature 0°C ~ 80°C
Base Product Number APDB
Wavelength 850nm
Viewing Angle 51°, 71°
Ultra Librarian 3D Model Ultra Librarian APDB-00 CAD Model

Description

The ams-OSRAM USA INC. APDB series is an infrared (IR) LED emitter.

  • Wavelength: 850nm
  • Voltage - Forward (Vf): 1.9V
  • Viewing Angle: 51° / 71°
  • Operating Temperature: 0°C ~ 80°C
  • Package / Case: 2-SMD, No Lead
  • Base Product Number: APDB
