Same model may have multiple batches, images only for reference.
10120850-002LF Amphenol – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

10120850-002LF

Part No 10120850-002LF
Manufacturer Amphenol
Catalog Card Edge Connectors - Edgeboard Connectors
Description CONN EDGE DUAL FMALE 68POS
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Card Type Non Specified - Dual Edge
Gender Female
Number of Positions/Bay/Row 18; 16
Number of Positions 68 (32 + 36 Power)
Card Thickness 0.062" (1.57mm)
Number of Rows 2
Read Out Dual
Features Board Lock
Mounting Type Through Hole
Termination Solder
Contact Material Copper Alloy
Contact Finish Gold or Gold, GXT™
Contact Type Cantilever
Color Black
Temperature Range - Operating -55°C ~ 105°C
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1614631-10120850-002LF
Ultra Librarian 3D Model Ultra Librarian 10120850-002LF CAD Model
