The A29L400ATV-70F is a 4 Mbit (512K x 8 or 256K x 16) CMOS Flash memory produced by Amic. It provides non-volatile storage suitable for a variety of embedded applications with fast read access and efficient power management. Its key feature is its ability to retain data even when power is removed, making it ideal for storing firmware, boot code, and other critical information.

Applications

• Embedded systems: for storing firmware and boot code.
• Networking equipment: for storing configuration data and operating system images.
• Industrial control systems: for storing program code and calibration data.
• Consumer electronics: such as set-top boxes and gaming consoles, for storing game code and user settings.
• Medical devices: for storing patient data and device configuration.

Features

• 4 Mbit (512K x 8 or 256K x 16) CMOS Flash Memory
• Fast access time: 70ns
• Single 3V power supply
• Sector Erase Architecture: Uniform 64 Kbyte sectors
• Erase Suspend/Resume: Supports interrupting erase operations to read data from other sectors
• Embedded Erase and Program Algorithms
• Automatic Program Timing
• Top Boot Sector configuration
• JEDEC standard pinout

Benefits

• Fast read access allows for quick boot-up and code execution.
• Low power consumption extends battery life in portable applications.
• Sector erase architecture allows for flexible memory management and efficient data updates.
• Erase Suspend/Resume feature ensures critical data can be accessed even during erase operations.
• Embedded algorithms simplify memory programming and reduce system overhead.
• Top Boot Sector configuration allows for easy implementation of bootloaders.
• Standard JEDEC pinout allows for easy integration into existing systems.

Additional Details

The A29L400ATV-70F operates from a single 3V power supply, making it suitable for low-power applications. The device supports a sector erase architecture, allowing individual sectors to be erased and reprogrammed without affecting other sectors. It also features an erase suspend/resume capability, which allows the erase operation to be interrupted so that data can be read from other sectors of the memory. The embedded erase and program algorithms simplifies the memory programming process.
