ACS770KCB-150B-PFF-T Real Image ACS770KCB-150B-PFF-T Real Image1 ACS770KCB-150B-PFF-T Real Image2
Same model may have multiple batches, images only for reference.
ACS770KCB-150B-PFF-T Real Image ACS770KCB-150B-PFF-T Real Image1 ACS770KCB-150B-PFF-T Real Image2
ACS770KCB-150B-PFF-T Real Image ACS770KCB-150B-PFF-T Real Image1 ACS770KCB-150B-PFF-T Real Image2
Same model may have multiple batches, images only for reference.

ACS770KCB-150B-PFF-T

Part No ACS770KCB-150B-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 150A AC/DC
Datasheet
ACS770KCB-150B-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Series ACS770
Package Tube
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 150A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 13.3mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±0.6%
Voltage - Supply 5V
Response Time 4.6µs
Current - Supply (Max) 15mA
Temperature Range - Operating -40°C ~ 125°C
Polarization Bidirectional
Mounting Type Through Hole
Package / Case 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Base Product Number ACS770
Standard Package 34 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 847811-ACS770KCB-150B-PFF-T
Ultra Librarian 3D Model Ultra Librarian ACS770KCB-150B-PFF-T CAD Model

Description

The ACS770KCB-150B-PFF-T is a current sensor designed for measuring AC/DC currents up to 150A. Allegro MicroSystems, LLC manufactures it.

  • Sensor Type: Hall Effect, open-loop
  • Current Range: Up to 150A AC/DC
  • Output: Ratiometric voltage
  • Sensitivity: 13.3mV/A
  • Supply Voltage: 5V
  • Frequency Range: DC to 120kHz
  • Mounting Type: Through-hole
  • Package: 5-CB formed leads, PFF package
  • Linearity: ±1%
  • Accuracy: ±0.6%
  • Response Time: 4.6μs
  • Operating Temperature: -40°C to 125°C
  • Product Status: Active
  • Application: Sensors and transducers
