Same model may have multiple batches, images only for reference.
ACS770ECB-200U-PFF-T Real Image ACS770ECB-200U-PFF-T Real Image1 ACS770ECB-200U-PFF-T Real Image2 ACS770ECB-200U-PFF-T Real Image3 ACS770ECB-200U-PFF-T Real Image4 ACS770ECB-200U-PFF-T Real Image5
ACS770ECB-200U-PFF-T Real Image ACS770ECB-200U-PFF-T Real Image1 ACS770ECB-200U-PFF-T Real Image2 ACS770ECB-200U-PFF-T Real Image3 ACS770ECB-200U-PFF-T Real Image4 ACS770ECB-200U-PFF-T Real Image5
Same model may have multiple batches, images only for reference.

ACS770ECB-200U-PFF-T

Part No ACS770ECB-200U-PFF-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 200A DC / Current Sensor 200A 1 Channel Hall Effect, Open Loop Unidirectional 5-CB Formed Leads, PFF
Datasheet
ACS770ECB-200U-PFF-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr Allegro MicroSystems
Series ACS770
Package Tube
For Measuring DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 200A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 20mV/A
Frequency DC ~ 120kHz
Linearity ±1%
Accuracy ±0.6%
Voltage - Supply 5V
Response Time 4.6µs
Current - Supply (Max) 15mA
Temperature Range - Operating -40°C ~ 85°C
Polarization Unidirectional
Mounting Type Through Hole
Package / Case 5-CB Formed Leads, PFF
Supplier Device Package 5-CB Module
Base Product Number ACS770
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 620-1537-5,2156-ACS770ECB-200U-PFF-T,ALLALLACS770ECB-200U-PFF-T
Standard Package 34
Win Source Part Number 1176352-ACS770ECB-200U-PFF-T
Ultra Librarian 3D Model Ultra Librarian ACS770ECB-200U-PFF-T CAD Model

Description

The ACS770ECB-200U-PFF-T is a unidirectional current sensor designed for DC measuring applications.

  • Sensor Type: Hall Effect, Open Loop
  • Current-Sensing Range: 200A
  • Sensitivity: 20mV/A
  • Linearity: ±1%
  • Output: Ratiometric, Voltage-based
  • Response Time: 4.6μs
  • Operating Temperature Range: -40°C to 85°C
  • Supply Voltage: 5V
  • Maximum Current Supply: 15mA
  • Package: 5-CB formed leads, PFF
  • Frequency Range: DC to 120kHz
  • Manufacturer: Allegro MicroSystems
  • Standard Package: 34
