F03P006S05D Tamura
Same model may have multiple batches, images only for reference.

F03P006S05D

Part No F03P006S05D
Manufacturer Tamura
Catalog Current Transducers
Description SENSOR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Tamura
Series F03P
Package Tray
Product Status Active
For Measuring AC
Sensor Type Flux Gate, Closed Loop
Current - Sensing 6A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 104.2mV/A
Frequency 300kHz
Linearity ±0.1%
Voltage - Supply 4.75V ~ 5.25V
Response Time 0.3µs
Current - Supply (Max) 25mA
Temperature Range - Operating -40°C ~ 105°C
Polarization Bidirectional
Mounting Type Through Hole
Package / Case Module
Standard Package 400 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 9030.33.3800
Win Source Part Number 497046-F03P006S05D
Ultra Librarian 3D Model Ultra Librarian F03P006S05D CAD Model

Description

The 497046-F03P006S05D is a current sensor designed for measuring AC current up to 6A.

  • Current Measurement: AC, up to 6A
  • Principle: Flux Gate
  • Configuration: Closed-Loop
  • Output Type: Ratiometric and Voltage
  • Response Time: 0.3µs
  • Current Supply: Up to 25mA
  • Operating Temperature Range: -40°C to 105°C
  • Package: Module
  • Mounting: Through-Hole
  • Manufacturer: Tamura
  • Status: Active
  • Category: Sensors and Transducers, Current Sensors
