ACS725LLCTR-30AB-T Real Image ACS725LLCTR-30AB-T real image23948
Same model may have multiple batches, images only for reference.
ACS725LLCTR-30AB-T Real Image ACS725LLCTR-30AB-T real image23948
ACS725LLCTR-30AB-T Real Image ACS725LLCTR-30AB-T real image23948
Same model may have multiple batches, images only for reference.

ACS725LLCTR-30AB-T

Part No ACS725LLCTR-30AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 30A 8SOIC
Datasheet
ACS725LLCTR-30AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Series Automotive, AEC-Q100
Package Tape & Reel
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Differential
Current - Sensing 30A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 44mV/A
Frequency DC ~ 120kHz
Linearity ±1.5%
Accuracy ±0.7%
Voltage - Supply 3V ~ 3.6V
Response Time 4µs
Current - Supply (Max) 14mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Base Product Number ACS725
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 847959-ACS725LLCTR-30AB-T
Ultra Librarian 3D Model Ultra Librarian ACS725LLCTR-30AB-T CAD Model

Description

The ACS725LLCTR-30AB-T is a current sensor designed for measuring AC/DC currents.

  • Output Type: Ratiometric and Voltage
  • Current Sensing Range: 30A
  • Temperature Range: -40°C to 150°C
  • Mounting Type: Surface Mount
