ACS725LLCTR-20AB-T Real Image ACS725LLCTR-20AB-T real image21492 ACS725LLCTR-20AB-T real image21493 ACS725LLCTR-20AB-T Real Image1 ACS725LLCTR-20AB-T Real Image2 ACS725LLCTR-20AB-T Real Image3 ACS725LLCTR-20AB-T Real Image4
Same model may have multiple batches, images only for reference.
ACS725LLCTR-20AB-T Real Image ACS725LLCTR-20AB-T real image21492 ACS725LLCTR-20AB-T real image21493 ACS725LLCTR-20AB-T Real Image1 ACS725LLCTR-20AB-T Real Image2 ACS725LLCTR-20AB-T Real Image3 ACS725LLCTR-20AB-T Real Image4
ACS725LLCTR-20AB-T Real Image ACS725LLCTR-20AB-T real image21492 ACS725LLCTR-20AB-T real image21493 ACS725LLCTR-20AB-T Real Image1 ACS725LLCTR-20AB-T Real Image2 ACS725LLCTR-20AB-T Real Image3 ACS725LLCTR-20AB-T Real Image4
Same model may have multiple batches, images only for reference.

ACS725LLCTR-20AB-T

Part No ACS725LLCTR-20AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 20A AC/DC
Datasheet
ACS725LLCTR-20AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring AC/DC
Sensor Type Hall Effect, Differential
Current - Sensing 20A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 66mV/A
Frequency DC ~ 120kHz
Linearity ±1.5%
Accuracy ±0.8%
Operating Supply Voltage 3 V ~ 3.6 V
Response Time 4μs
Maximum Supply Current 14mA
Operating Temperature Range -40°C ~ 150°C
Polarization Bidirectional
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 766993-ACS725LLCTR-20AB-T
Popularity Medium
Supply and Demand Status Balance
Family Name ACS725
Introduction Date March 17, 2015
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian ACS725LLCTR-20AB-T CAD Model

Description

The ACS725LLCTR-20AB-T from Allegro MicroSystems, LLC is a hall effect, differential sensor type that is ideal for measuring AC/DC.

  • Package: 8-SOIC (0.154", 3.90mm Width)
  • Mounting: SMD
  • Temperature Range: -40°C to 150°C
  • Sensitivity: 66mV/A
  • Supply and Demand Status: balance
  • Family Name: ACS725
  • Output: ratiometric, voltage
  • Response Time: 4μs
  • Current-Sensing: 20A
  • Linearity: ±1.5%
  • Accuracy: ±0.8%
  • Maximum Supply Current: 14mA
  • Introduction Date: March 17, 2015
  • ECCN: EAR99
  • Estimated EOL Date: 2025
  • Halogen-Free Compliant: Yes
  • Manufactured In: Philippines
