ACS722LLCTR-40AB-T Real Image ACS722LLCTR-40AB-T Real Image1 ACS722LLCTR-40AB-T Real Image2
Same model may have multiple batches, images only for reference.
ACS722LLCTR-40AB-T Real Image ACS722LLCTR-40AB-T Real Image1 ACS722LLCTR-40AB-T Real Image2
ACS722LLCTR-40AB-T Real Image ACS722LLCTR-40AB-T Real Image1 ACS722LLCTR-40AB-T Real Image2
Same model may have multiple batches, images only for reference.

ACS722LLCTR-40AB-T

Part No ACS722LLCTR-40AB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 40A AC/DC / Current Sensor 40A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
Datasheet
ACS722LLCTR-40AB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Current Sensors
Mfr Allegro MicroSystems, LLC
Package Tape & Reel
Product Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 40A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 33mV/A
Frequency DC ~ 80kHz
Linearity ±1%
Accuracy ±3%
Voltage - Supply 3V ~ 3.6V
Response Time 5µs
Current - Supply (Max) 12mA
Temperature Range - Operating -40°C ~ 150°C
Polarization Bidirectional
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOIC
Base Product Number ACS722
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 848157-ACS722LLCTR-40AB-T
Ultra Librarian 3D Model Ultra Librarian ACS722LLCTR-40AB-T CAD Model

Description

The ACS722LLCTR-40AB-T is a current sensor designed for measuring AC and DC currents up to 40A from Allegro MicroSystems, LLC.

  • Technology: Hall Effect (Open-Loop)
  • Sensitivity: 33mV/A
  • Response Time: 5µs
  • Output: Ratiometric, Voltage-Based
  • Supply Voltage: 3V to 3.6V
  • Maximum Current Consumption: 12mA
  • Package: 8-SOIC
  • Mounting: Surface Mount
  • Operating Temperature Range: -40°C to 150°C
  • Accuracy: ±1% and ±3%
