ACS714LLCTR-50A-T Real Image ACS714LLCTR-50A-T real image21477 ACS714LLCTR-50A-T Real Image1 ACS714LLCTR-50A-T Real Image2
Same model may have multiple batches, images only for reference.
ACS714LLCTR-50A-T Real Image ACS714LLCTR-50A-T real image21477 ACS714LLCTR-50A-T Real Image1 ACS714LLCTR-50A-T Real Image2
ACS714LLCTR-50A-T Real Image ACS714LLCTR-50A-T real image21477 ACS714LLCTR-50A-T Real Image1 ACS714LLCTR-50A-T Real Image2
Same model may have multiple batches, images only for reference.

ACS714LLCTR-50A-T

Part No ACS714LLCTR-50A-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 50A AC/DC
Datasheet
ACS714LLCTR-50A-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel package
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 50A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 40mV/A
Frequency DC ~ 80kHz
Linearity ±1.5%
Accuracy ±1.5%
Operating Supply Voltage 5V
Response Time 5μs
Maximum Supply Current 13mA
Operating Temperature Range -40°C ~ 150°C
Polarization Bidirectional
Mounting SMD
Package 8-SOIC (0.154", 3.90mm Width)
Win Source Part Number 766978-ACS714LLCTR-50A-T
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Family Name ACS714
Introduction Date December 11, 2007
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2021
Ultra Librarian 3D Model Ultra Librarian ACS714LLCTR-50A-T CAD Model

Description

The ACS714LLCTR-50A-T is a Hall-effect open-loop bidirectional current sensor IC from Allegro MicroSystems.

  • Current-Sensing: 50A
  • Sensitivity: 40mV/A
  • Output: Ratiometric voltage
  • Supply Voltage: 5V
  • Response Time: 5μs
  • Package Type: 8-SOIC (0.154", 3.90mm Width)
  • Mounting: SMD
  • Quantity per package: 3k pcs
