The AAT2113AIXS-1.2-T1 is a high-efficiency, synchronous step-down DC-DC converter manufactured by Advanced Analog Technology. It's designed to provide a regulated 1.2V output voltage from a wide input voltage range. The device is ideal for battery-powered applications where efficiency and small size are critical.

Applications

• Portable devices
• Battery-powered systems
• Point-of-load regulators
• Wireless communication devices
• Handheld instruments

Features

• High efficiency up to 95%
• Synchronous rectification
• Wide input voltage range
• Fixed 1.2V output voltage
• Short-circuit protection
• Over-temperature protection
• Small SOT23 package

Benefits

• Extended battery life due to high efficiency
• Reduced power dissipation and heat generation
• Stable and accurate output voltage regulation
• Protection against damage from short circuits and over-temperature conditions
• Compact solution for space-constrained applications
• Simplified design with minimal external components

Technical Specifications

The key specifications include:

• Input Voltage Range: 2.7V to 5.5V
• Output Voltage: 1.2V (fixed)
• Output Current: Up to 600mA
• Switching Frequency: 1.5 MHz
• Efficiency: Up to 95%
• Operating Temperature Range: -40°C to +85°C

The AAT2113AIXS-1.2-T1 is commonly used in smartphones, tablets, MP3 players, and other portable electronic devices. Its high efficiency and small size make it an excellent choice for applications requiring long battery life and compact design.
