Analog Devices Inc.

The AD9265BCPZ-80 is a high-performance, 16-bit analog-to-digital converter (ADC) from Analog Devices Inc., designed to provide exceptional accuracy and speed for a wide range of applications. This ADC operates at a conversion rate of 80 MSPS (mega-samples per second), making it an ideal choice for advanced digital data acquisition systems.

Key Features

• Resolution: 16-bit with no missing codes
• Sample Rate: Up to 80 MSPS, enabling high-speed data acquisition
• Input Range: Differential input with a 2 Vpp to 2.5 Vpp range
• Interface: Serial LVDS (Low-Voltage Differential Signaling) or CMOS outputs
• Power Consumption: Low power operation with a typical consumption of 140 mW at 80 MSPS
• Package: Compact 32-lead LFCSP (Lead Frame Chip Scale Package)
• Integrated Features: On-chip voltage reference and sample-and-hold circuit
• SNR: High signal-to-noise ratio for precise signal acquisition

Applications

The AD9265BCPZ-80 is versatile and can be used in a variety of high-speed signal processing applications, including:

• Medical Imaging Systems
• Communications Infrastructure
• Radar and Satellite Antenna Array Processing
• Instrumentation and Test Equipment
• Data Acquisition Systems

Performance and Quality

Analog Devices Inc. is known for its commitment to performance and quality, and the AD9265BCPZ-80 is no exception. With its robust design and advanced technology, this ADC delivers reliable and consistent performance that engineers and designers can trust for their critical applications.

Ordering Information

To purchase or request samples of the AD9265BCPZ-80, visit the Analog Devices Inc. website or contact an authorized distributor. Ensure you have the correct part number (AD9265BCPZ-80) to get the exact product specifications for your needs.
