Mfr. Part No. Qty. Price

No items in the cart

View Cart
Same model may have multiple batches, images only for reference.
2974 Real Image
Same model may have multiple batches, images only for reference.

2974

Part No 2974
Manufacturer Adafruit Industries LLC
Catalog Display Modules - LED Dot Matrix and Cluster
Description LED CHARLIEPLEXED MATRIX - 9X16
Datasheet
2974 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Optoelectronics - LED Dot Matrix and Cluster
Mfr Adafruit Industries LLC
Package Bulk
Product Status Active
Size / Dimension 1.70" L x 1.10" W x 0.09" H (43.18mm x 27.94mm x 2.29mm)
Color White
Configuration 9 x 16
Interface I2C
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.41.0000
California Prop 65 Warning Information
Win Source Part Number 854937-2974
Ultra Librarian 3D Model Ultra Librarian 2974 CAD Model

Description

The LED Dot Matrix and Cluster 854937-2974 is a compact and versatile optoelectronic component.

  • Color: White
  • Configuration: 9 x 16
  • Interface: I²C
  • Package Size: 1.70" L x 1.10" W x 0.09" H
  • Manufacturer: Adafruit Industries LLC
  • Status: Active
