Same model may have multiple batches, images only for reference.
TYN16-800RTQ WeEn Semiconductors
Same model may have multiple batches, images only for reference.

TYN16-800RTQ

Part No TYN16-800RTQ
Manufacturer WeEn Semiconductors
Catalog SCRs - Single
Description SCR 800V 16A TO220AB / SCR 800 V 16 A Standard Recovery Through Hole TO-220AB
Datasheet
TYN16-800RTQ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Thyristors - SCRs
Mfr WeEn Semiconductors
Package Tube
Voltage - Off State 800 V
Voltage - Gate Trigger (Vgt) (Max) 1.3 V
Current - Gate Trigger (Igt) (Max) 25 mA
Voltage - On State (Vtm) (Max) 1.5 V
Current - On State (It (AV)) (Max) 10.2 A
Current - On State (It (RMS)) (Max) 16 A
Current - Hold (Ih) (Max) 40 mA
Current - Off State (Max) 1 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 210A, 231A
SCR Type Standard Recovery
Temperature Range - Operating -40°C ~ 150°C
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220AB
Base Product Number TYN16
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.30.0080
Other Names 934066185127
Standard Package 1,000
Win Source Part Number 1000972-TYN16-800RTQ
Ultra Librarian 3D Model Ultra Librarian TYN16-800RTQ CAD Model

Description

The TYN16-800RTQ is a discrete semiconductor product manufactured by WeEn Semiconductors.

  • Voltage Off State: 800V
  • Maximum Current On State: 10.2A
  • Package: TO-220-3
  • Supplier Device Package: TO-220AB
