Products specifications

Category Resistors>Chip Resistor - Surface Mount
Mfr Vishay Dale
Series WSR
Package Tape & Reel
Resistance 200 mOhms
Tolerance ±1%
Power (Watts) 5W
Composition Metal Element
Features Anti-Sulfur, Automotive AEC-Q200, Current Sense, Moisture Resistant, Pulse Withstanding
Temperature Coefficient ±75ppm/°C
Temperature Range - Operating -65°C ~ 275°C
Package / Case 4527 J-Lead
Supplier Device Package 4527
Ratings AEC-Q200
Dimension 0.455" L x 0.275" W (11.56mm x 6.98mm)
Height - Seated (Max) 0.100" (2.54mm)
Number of Terminations 2
Other Names WSRC-.2CT,WSRC-.2TR,WSRC-.2DKR
Standard Package 1,500
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8533.21.0030
Win Source Part Number 1236320-WSR5R2000FEA
Ultra Librarian 3D Model Ultra Librarian WSR5R2000FEA CAD Model

Description

The Vishay Dale WSR series chip resistor is a high-quality and reliable surface mount resistor designed for use in automotive applications. With a resistance of 200 mOhms, a tolerance of ±1%, and a temperature coefficient of ±75ppm/°C, this metal element resistor is ideal for use as a current sense resistor in a variety of automotive applications.

  • Pulse-withstanding: Yes
  • AEC-Q200 Applications: Yes
  • Package: Tape and Reel
  • Dimensions: 4527 J-Lead
  • Height: 0.100" (2.54mm)
  • Standard Package: 1,500 pieces
