VS-20BQ030PBF Real Image VS-20BQ030PBF Real Image
Same model may have multiple batches, images only for reference.
VS-20BQ030PBF Real Image VS-20BQ030PBF Real Image
VS-20BQ030PBF Real Image VS-20BQ030PBF Real Image
Same model may have multiple batches, images only for reference.

VS-20BQ030PBF

Part No VS-20BQ030PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 2A SMB
Datasheet
VS-20BQ030PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Bulk
Status Obsolete(EOL)
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 470mV @ 2A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 30V
Mounting SMD (SMT)
Case / Package SMB
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 110791-VS-20BQ030PBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian VS-20BQ030PBF CAD Model

Description

The Vishay 110791-VS-20BQ030PBF is a Schottky diode with a maximum reverse voltage of 30V and an average rectified current of 2A.

  • Manufacturer: Vishay
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Current - Average Rectified (Io): 2A
  • Voltage - Forward (Vf) @ If: 470mV @ 2A
  • Current - Reverse Leakage @ Vr: 500μA @ 30V
  • Speed (Frequency): Fast Recovery = 200mA (Io)
  • Package / Case: SMB
  • Operating Temperature: -55 to 150°C
  • Product Category: Discrete Semiconductor Products
  • Product Status: Obsolete (EOL)
