VOM617AT Real Image VOM617AT Real Image
Same model may have multiple batches, images only for reference.
VOM617AT Real Image VOM617AT Real Image
VOM617AT Real Image VOM617AT Real Image
Same model may have multiple batches, images only for reference.

VOM617AT

Part No VOM617AT
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Low Input Current, Phototransistor Output, SOP-4, Mini-Flat Package
Datasheet
VOM617AT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay Semiconductor Opto Division
Packaging Reel - TR
Number of Channels 1
Voltage - Isolation 3750Vrms
Current Transfer Ratio (Minimum) 50% @ 5mA
Current Transfer Ratio (Maximum) 600% @ 5mA
Turn On / Turn Off Time (Typ) 6μs, 4μs
Rise / Fall Time (Typ) 3μs, 3μs
Input Type DC
Output Type Transistor
Output Voltage MAX 80V
Output Current per Channel 50mA
Voltage - Forward (Vf) (Typ) 1.1V
Current - DC Forward (If) (Maximum) 60mA
Vce Saturation (Maximum) 400mV
Operating Temperature Range -55°C ~ 110°C
Mounting SMD
Package 4-SMD, Gull Wing
Manufacturer Package 4-SOP (2.54mm)
Win Source Part Number 1279721-VOM617AT
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Balance
Family Name VOM617A
Introduction Date August 27, 2012
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian VOM617AT CAD Model

Description

The VOM617AT electronic component is manufactured by Vishay Semiconductor Opto Division.

  • Supply and Demand Status: balance
  • Manufacturer: Vishay Semiconductor Opto Division
  • Manufacturer Homepage: www.vishay.com
  • Package: 4-SMD, Gull Wing
  • Operating Temperature: -55°C to 110°C
  • Output Type: transistor
  • Input Type: DC
  • Voltage - Forward (Vf) (Typ): 1.1V
  • Output Voltage MAX: 80V
  • Turn on / Turn off Time (Typ): 6μs, 4μs
  • Rise / Fall Time (Typ): 3μs, 3μs
  • Number of Channels: 1
  • Voltage - Isolation: 3750Vrms
  • Current Transfer Ratio (Minimum): 50% @ 5mA
  • Current Transfer Ratio (Maximum): 600% @ 5mA
  • Vce Saturation (Maximum): 400mV
  • Alternative Parts (Cross-Reference): PS2711-1-M-A, PS2701-1, and PS2701A-1-F3-M-A
  • Introduction Date: August 27, 2012
  • ECCN: EAR99
  • Country of Origin: China
  • Estimated EOL Date: 2022
  • Halogen Free: true
  • Category: isolators
