UHB20FCT-E3/8W Vishay UHB20FCT-E3/8W Real Image UHB20FCT-E3/8W real image
Same model may have multiple batches, images only for reference.
UHB20FCT-E3/8W Vishay UHB20FCT-E3/8W Real Image UHB20FCT-E3/8W real image
UHB20FCT-E3/8W Vishay UHB20FCT-E3/8W Real Image UHB20FCT-E3/8W real image
Same model may have multiple batches, images only for reference.

UHB20FCT-E3/8W

Part No UHB20FCT-E3/8W
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY GP 300V 10A TO263AB / Diode Switching 300V 20A 3-Pin(2+Tab) TO-263AB T/R
Datasheet
UHB20FCT-E3/8W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 300V
Current - Average Rectified (Io) (per Diode) 10A
Voltage - Forward (Vf) (Max) @ If 1.2V @ 10A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 35ns
Current - Reverse Leakage @ Vr 5μA @ 300V
Operating Temperature - Junction -55°C to 175°C
Mounting SMD (SMT)
Case / Package TO-263AB
Win Source Part Number 057255-UHB20FCT-E3/8W
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name UHB20FCT
Introduction Date August 28, 2007
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian UHB20FCT-E3/8W CAD Model

Description

The 057255-UHB20FCT-E3/8W is a standard diode from Vishay.

  • Maximum Reverse Voltage: 300V
  • Forward Voltage: 1.2V @ 10A
  • Diode Configuration: 1 pair common cathode
  • Current Rating: 10A
  • Operating Temperature Range: -55°C to 175°C
  • Recovery Speed: 200mA (Io)
  • Reverse Recovery Time (trr): 35ns
  • Current Leakage @ Reverse Voltage: 5µA @ 300V
