Same model may have multiple batches, images only for reference.
TSOP36236TT Real Image
Same model may have multiple batches, images only for reference.

TSOP36236TT

Part No TSOP36236TT
Manufacturer Vishay
Catalog Optical Sensors - Photo Detectors - Remote Receiver
Description MOD IR RCVR 36KHZ TOP VW SMD
Datasheet
TSOP36236TT Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Vishay
Packaging Reel - TR
Status Active
Sensing Distance 45m
Carrier Frequency 36.0kHz
Supply Voltage - Operating 2.5 V to 5.5 V
Operating Supply Current 350μA
Orientation Side or Top View
Mounting SMD (SMT)
Temperature Range - Operating -25°C to 85°C (TA)
Win Source Part Number 057160-TSOP36236TT
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TSOP36236TT CAD Model

Description

The Vishay TSOP36236TT is a sensor that is used in transducers.

  • Sensing Distance: 45m
  • Temperature Range: -25°C to 85°C
  • Operating Supply Voltage: 2.5V to 5.5V
  • Operating Supply Current: 350μA
  • Popularity: Medium
