SSA34-E3/61T Vishay SSA34-E3/61T label picture SSA34-E3/61T real image
Same model may have multiple batches, images only for reference.
SSA34-E3/61T Vishay SSA34-E3/61T label picture SSA34-E3/61T real image
SSA34-E3/61T Vishay SSA34-E3/61T label picture SSA34-E3/61T real image
Same model may have multiple batches, images only for reference.

SSA34-E3/61T

Part No SSA34-E3/61T
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 3A DO214AC / Rectifier Diode Schottky 40V 3A 2-Pin SMA T/R
Datasheet
SSA34-E3/61T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 490mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 200μA @ 40V
Mounting SMD (SMT)
Case / Package DO-214AC (SMA)
Operating Temperature - Junction -65°C to 150°C
Win Source Part Number 095547-SSA34-E3/61T
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management, Automotive, Commercial, Industrial
Family Name SSA34
Introduction Date November 13, 2003
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian SSA34-E3/61T CAD Model

Description

The Vishay 095547-SSA34-E3/61T is a high popularity Schottky diode used in power management, automotive, commercial, and industrial applications.

  • Manufacturer: Vishay
  • Recovery Speed: 200mA
  • Maximum Reverse Voltage: 40V
  • Forward Voltage: 490mV @ 3A
  • Reverse Leakage Current: 200μA @ 40V
  • Package: DO-214AC (SMA)
  • Halogen-Free: Compliant
  • Component Status: Active
