SM6T6V8AHE3_A/H Real Image SM6T6V8AHE3_A/H real image17760
Same model may have multiple batches, images only for reference.
SM6T6V8AHE3_A/H Real Image SM6T6V8AHE3_A/H real image17760
SM6T6V8AHE3_A/H Real Image SM6T6V8AHE3_A/H real image17760
Same model may have multiple batches, images only for reference.

SM6T6V8AHE3_A/H

Part No SM6T6V8AHE3_A/H
Manufacturer Vishay
Catalog TVS - Diodes
Datasheet
SM6T6V8AHE3_A/H Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>TVS - Diodes
Mfr Vishay General Semiconductor - Diodes Division
Series Automotive, AEC-Q101, SM6T, TransZorb®
Package Tape & Reel (TR)
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 5.8V
Voltage - Breakdown (Min) 6.45V
Voltage - Clamping (Max) @ Ipp 10.5V
Current - Peak Pulse (10/1000µs) 57A
Power - Peak Pulse 600W
Power Line Protection No
Applications Automotive
Temperature Range - Operating -65°C ~ 150°C (TJ)
Mounting SMD (SMT)
Package / Case DO-214AA, SMB
Supplier Device Package DO-214AA (SMBJ)
Base Product Number SM6T6V8
Standard Package 750
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1298147-SM6T6V8AHE3_A/H
Ultra Librarian 3D Model Ultra Librarian SM6T6V8AHE3_A/H CAD Model

Description

Vishay General Semiconductor - Diodes Division presents its SM6T6V8AHE3_A/H TransZorb series Zener diode designed for automotive use.

  • Package: Tape & Reel (TR)
  • Mounting: SMD (SMT) technology
  • Voltage - Reverse Standoff (typ): 5.8V
  • Voltage - Breakdown (min): 6.45V
  • Voltage - Clamping (max) @ Ipp: 10.5V
  • Power - Peak Pulse: 600W
  • Channel: Unidirectional channel
  • Designed for: Use in automotive applications
  • Standard Package: 750 pieces
  • Temperature Range: -65°C to 150°C (TJ)
  • HTSUS Code: 8541.10.0080
  • Base Product Number: SM6T6V8
