MBRB25H45CTHE3/81 Real Image MBRB25H45CTHE3/81 Real Image
Same model may have multiple batches, images only for reference.
MBRB25H45CTHE3/81 Real Image MBRB25H45CTHE3/81 Real Image
MBRB25H45CTHE3/81 Real Image MBRB25H45CTHE3/81 Real Image
Same model may have multiple batches, images only for reference.

MBRB25H45CTHE3/81

Part No MBRB25H45CTHE3/81
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 45V TO263AB
Datasheet
MBRB25H45CTHE3/81 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Features Diode Array 1 Pair Common Cathode Schottky 45 V 15A Surface Mount TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Manufacturer Vishay
Package Reel - TR
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Surface Mount
Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Case / Package TO-263AB (D2PAK)
Family Name MBRB25
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Quantity per package 800
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 883166-MBRB25H45CTHE3/81
Ultra Librarian 3D Model Ultra Librarian MBRB25H45CTHE3/81 CAD Model

Description

The MBRB25H45CTHE3/81 is a diode array from Vishay.

  • Configuration: 1 Pair Common Cathode Schottky
  • Recovery Speed: < 500ns, > 200mA
  • Package: TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
  • Mounting Type: Surface Mountable
  • Status: Discontinued @ Digi-Key
  • Family: MBRB25
  • Category: Discrete Semiconductor Products
  • ECCN: EAR99
  • Supply and Demand Status: Limited
  • MSL Level: 1 (unlimited)
  • REACH: REACH unaffected
  • HTSUS: 8541.10.0080
