IRFP9240 real image11752

Same model may have multiple batches, images only for reference.

IRFP9240 Vishay

IRFP9240 real image11752

Same model may have multiple batches, images only for reference.

IRFP9240

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRFP9240
Manufacturer	Vishay
Catalog	FETs - Single
Description	P-CHANNEL POWER MOSFETS \| MOSFET P-CH 200V 12A TO-247AC
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Siliconix
Packaging	Tube
Status	Obsolete
Transistor Polarity	P-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	200V
Id - Continuous Drain Current	12A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	500mOhm at 7.2A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	44nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	1200pF at 25V
Power Dissipation (Maximum)	150W
Temperature Range - Operating	-55°C ~ 150°C
Mounting Style	Through Hole
Supplier Device Package	TO-247-3
Manufacturer Package	TO-247-3
Manufacturer Pack Quantity	500
MSL Level	1 (Unlimited)
Win Source Part Number	1187812-IRFP9240
Manufacturer Homepage	www.samsung.com/Products/Semiconductor
Popularity	Medium
Supply and Demand Status	Limited
Application Field	Used in Power Management
Ultra Librarian 3D Model	Ultra Librarian IRFP9240 CAD Model

Alternative Products

Description

The MOSFET is a P-Channel transistor with a maximum power dissipation of 150W. It has a drive voltage of 10V and a Vds - Drain-Source Breakdown Voltage of 200V. Vishay Siliconix

Transistor Type: P-Channel
Maximum Power Dissipation: 150W
Drive Voltage: 10V
Drain-Source Breakdown Voltage: 200V
Package: TO-247-3
Gate Source Voltage (maximum): ±20V
Input Capacitance (Ciss) (maximum) @ Vds: 1200pF @ 25V
Supply and Demand: Limited
Status: Obsolete
