ICM0805ER670M Vishay – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ICM0805ER670M

Part No ICM0805ER670M
Manufacturer Vishay
Catalog Common Mode Chokes
Description CMC 400MA 2LN 67 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 67 Ohms @ 100 MHz
Current Rating (Max) 400mA
DC Resistance (DCR) (Max) 250mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Size / Dimension 0.079" L x 0.047" W (2.00mm x 1.20mm)
Height (Max) 0.057" (1.45mm)
Case / Package Horizontal, 4 PC Pad
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1530554-ICM0805ER670M
Ultra Librarian 3D Model Ultra Librarian ICM0805ER670M CAD Model
