DG406DW-E3 Real Image DG406DW-E3 Real Image1 DG406DW-E3 Real Image2
DG406DW-E3 Real Image DG406DW-E3 Real Image1 DG406DW-E3 Real Image2
Same model may have multiple batches, images only for reference.

DG406DW-E3

Part No DG406DW-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description 16-Ch/Dual 8-Ch High-Performance CMOS Analog Multiplexers
Datasheet
DG406DW-E3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Vishay
Packaging Tube
Number of Circuits 1
On-State Resistance (Maximum) 100 Ohm
Channel-to-Channel Matching (ΔRon) 5 Ohm
Operating Supply Voltage 12V
Dual Voltage Supply ±5 V ~ 20 V
Switch Time (Ton, Toff) (Maximum) 200ns, 150ns
Charge Injection 15pC
Channel Capacitance (CS(off), CD(off)) 8pF, 130pF
Current - Leakage (IS(off)) (Maximum) 500pA
Operating Temperature Range -40°C ~ 85°C (TA)
Package 28-SOIC (0.295", 7.50mm Width)
Manufacturer Package 28-SOIC
Win Source Part Number 1167470-DG406DW-E3
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DG406DW-E3 CAD Model

Description

The Vishay DG406DW-E3 is a 28-SOIC (0.295", 7.50mm Width) integrated circuit switch with a dual voltage supply of ±5 V ~ 20 V.

  • On-State Resistance (Maximum): 100 Ohm
  • Switch Time (Ton, Toff) (Maximum): 200ns, 150ns
  • Operating Temperature Range: -40°C ~ 85°C (TA)
  • Package: Tube with 1 circuit
  • Operating Supply Voltage: 12V
  • Channel-to-Channel Matching (ΔRon): 5 Ohm
  • Channel Capacitance (CS(off), CD(off)): 8pF, 130pF
  • Current - Leakage (IS(off)) (Maximum): 500pA
  • Charge Injection: 15pC
  • Market Status: open market
  • ECCN: EAR99 product
  • HTSUS Code: Not provided
