Part No CNY17F-1X007
Manufacturer Vishay
Catalog Optoisolators - Transistor, Photovoltaic Output
Description Optocoupler, Phototransistor Output, No Base Connection
Datasheet
CNY17F-1X007 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Vishay Semiconductor Opto Division
Packaging Tube
Number of Channels 1
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 40% @ 10mA
Current Transfer Ratio (Maximum) 80% @ 10mA
Turn On / Turn Off Time (Typ) 3μs, 2.3μs
Rise / Fall Time (Typ) 2μs, 2μs
Input Type DC
Output Type Transistor
Output Voltage MAX 70V
Output Current per Channel 50mA
Voltage - Forward (Vf) (Typ) 1.39V
Current - DC Forward (If) (Maximum) 60mA
Vce Saturation (Maximum) 400mV
Operating Temperature Range -55°C ~ 110°C
Mounting SMD
Package 6-SMD, Gull Wing
Manufacturer Package 6-SMD
Win Source Part Number 1162644-CNY17F-1X007
Manufacturer Homepage www.vishay.com
Popularity Medium
Supply and Demand Status Limited
Family Name CNY17F
Introduction Date September 12, 2001
ECCN EAR99
Country of Origin China
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian CNY17F-1X007 CAD Model

Description

The CNY17F-1X007 is a single channel, high isolation voltage optocoupler consisting of a phototransistor optically coupled to a gallium arsenide infrared emitting diode.

  • Product Name: CNY17F-1X007
  • Channels: Single channel
  • Type: High isolation voltage optocoupler
  • Components: Phototransistor & gallium arsenide infrared emitting diode
  • Package: 6-SMD, gull wing
  • Isolation Voltage: 5,000 Vrms (minimum)
  • Operating Temperature: -55°C to 110°C
  • Ideal For: Industrial control, medical equipment, and communication systems
  • Current Transfer Ratio: 40% to 80% @ 10mA
  • Maximum Forward Voltage: 1.39V
  • Maximum Saturation Voltage: 400mV
  • Alternative Parts: CNY17F-3S(TA), CNY17F-4S(TA), and CNY17F-1S(TA)
