Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Status Obsolete
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 400V
Current - Average Rectified (Io) 50A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage at Vr 5mA at 400V
Mounting Style Chassis, Stud Mount
Manufacturer Package B-47
Supplier Device Package B-47
Operating Temperature - Junction -65°C ~ 195°C
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1134104-8AF4NPP
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 8AF4NPP CAD Model

Description

The 8AF4NPP is an electronic component manufactured by Vishay Semiconductor Diodes Division.

  • Status: Obsolete
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • Win Source Part Number: 1134104-8AF4NPP
  • Packaging: Bulk
  • Mounting Style: Chassis, stud mount
  • Diode Type: Standard
  • Current - Average Rectified (Io): 50A
  • Operating Temperature - Junction: -65°C ~ 195°C
  • Voltage - DC Reverse (Vr) (Maximum): 400V
  • Supplier Device Package: B-47
  • Manufacturer Package: B-47
  • Current - Reverse Leakage @ Vr: 5mA @ 400V
  • Capacitance @ Vr, F: -
