60CPQ150PBF Real Image 60CPQ150PBF Real Image
Same model may have multiple batches, images only for reference.
60CPQ150PBF Real Image 60CPQ150PBF Real Image
60CPQ150PBF Real Image 60CPQ150PBF Real Image
Same model may have multiple batches, images only for reference.

60CPQ150PBF

Part No 60CPQ150PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 150V TO247
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 150V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 830mV @ 30A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 100μA @ 150V
Operating Temperature - Junction -55°C to 175°C
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 089192-60CPQ150PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 60CPQ150PBF CAD Model

Description

Product Overview

The 60CPQ150PBF is a dual Schottky barrier rectifier offering enhanced performance for high-frequency systems, ensuring reliability even at elevated temperatures.

Applications

  • Renewable energy systems
  • Electric vehicles
  • High-frequency power conversion
  • Semiconductor testing equipment

Features and Benefits

  • Enhanced thermal resistance
  • Dual circuit design for flexibility
  • Environmentally friendly construction
  • Optimized for high efficiency

For designers looking to incorporate efficient thermal management, the 60CPQ150PBF is an ideal solution.
