Products specifications

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Bulk
Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 1000V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 1.1V @ 2A
Current - Reverse Leakage @ Vr 5μA @ 1000V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package WOG
Win Source Part Number 111172-2W10G-E4/51
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name 2W10G
Introduction Date June 18, 1998
ECCN EAR99
Country of Origin China
Halogen Free Unknown
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian 2W10G-E4/51 CAD Model

Description

Product Overview

The 2W10G-E4/51 rectifier diode is designed for use in high-current environments. It offers reliable performance with an emphasis on efficiency and low thermal resistance, making it ideal for a wide range of electronic applications.

Applications and Projects

  • High-Efficiency Power Supplies
  • DC-DC Converters
  • Uninterruptible Power Supplies (UPS)
  • Electric Vehicle Charging Stations

Features and Benefits

  • High Current Capacity: Suitable for high-demand applications.
  • Low Thermal Resistance: Guarantees improved heat dissipation.
  • Optimized Footprint: Maintains high performance in a compact design.
  • Extended Reliability: Built for long-term use in varying environments.

Additional Details: The 2W10G-E4/51 is engineered to offer seamless integration in cutting-edge electronic systems, ensuring efficiency and reliability even under continuous operation.
