Products specifications

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Bulk
Status Obsolete(EOL)
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 45V
Current - Average Rectified (Io) (per Diode) 150A
Voltage - Forward (Vf) (Max) @ If 920mV @ 150A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 5mA @ 45V
Operating Temperature - Junction -55°C to 175°C
Mounting Through Hole
Case / Package D-60
Win Source Part Number 197296-151CMQ045
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 151CMQ045 CAD Model

Description

151CMQ045 Schottky Rectifier Diode

The 151CMQ045 is a Schottky Rectifier Diode, designed to offer high efficiency and reliable performance in power supply applications. It features a low forward voltage drop and high current capability, making it ideal for use in low-voltage, high-frequency power circuits.

  • Features and Benefits:
  • Low forward voltage drop.
  • High surge capability.
  • Reliable and efficient power rectification.
  • Applications:
  • Switching power supplies.
  • DC-DC converters.
  • Battery chargers.
  • Solar inverters.

With its compact design and robust performance, the 151CMQ045 is a versatile component for a wide range of electronic projects.
