UM3483EESA Real Image UM3483EESA real image13789 UM3483EESA Real Image1 UM3483EESA Real Image2 UM3483EESA Real Image3 UM3483EESA Real Image4 UM3483EESA Real Image5 UM3483EESA Real Image6 UM3483EESA Real Image7 UM3483EESA Real Image8 UM3483EESA Real Image9
Same model may have multiple batches, images only for reference.
UM3483EESA Real Image UM3483EESA real image13789 UM3483EESA Real Image1 UM3483EESA Real Image2 UM3483EESA Real Image3 UM3483EESA Real Image4 UM3483EESA Real Image5 UM3483EESA Real Image6 UM3483EESA Real Image7 UM3483EESA Real Image8 UM3483EESA Real Image9
UM3483EESA Real Image UM3483EESA real image13789 UM3483EESA Real Image1 UM3483EESA Real Image2 UM3483EESA Real Image3 UM3483EESA Real Image4 UM3483EESA Real Image5 UM3483EESA Real Image6 UM3483EESA Real Image7 UM3483EESA Real Image8 UM3483EESA Real Image9
Same model may have multiple batches, images only for reference.

UM3483EESA

Part No UM3483EESA
Manufacturer Union Semiconductor
Catalog Interface - Drivers, Receivers, Transceivers
Description 3V TO 5.5V RS485 / 1/1 Transceiver Half RS485 8-SOP
Datasheet
UM3483EESA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Drivers, Receivers, Transceivers
Mfr Union Semiconductor
Series UM3243
Package Tape & Reel
Product Status Active
Type Transceiver
Protocol RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 25 mV
Data Rate 500kbps
Voltage - Supply 3V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOP
Standard Package 2 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 694460-UM3483EESA
Ultra Librarian 3D Model Ultra Librarian UM3483EESA CAD Model

Description

The 694460-UM3483EESA is a half-duplex RS485 transceiver integrated circuit.

  • Data Rate: 500kbps
  • Voltage Supply Range: 3V to 5.5V
  • Receiver Hysteresis: 25mV
  • Operating Temperature Range: -40°C to 85°C
