Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Drivers, Receivers, Transceivers
Mfr Union Semiconductor
Package Tape & Reel
Product Status Active
Type Transceiver
Protocol RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 100 mV
Data Rate 500kbps
Voltage - Supply 4.75V ~ 5.25V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package 8-SOP
Standard Package 2 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 694454-UM3085EESA
Ultra Librarian 3D Model Ultra Librarian UM3085EESA CAD Model

Description

The 694454-UM3085EESA is a Transceiver integrated circuit (IC) from Union Semiconductor.

  • Designed for: RS485 protocol.
  • Package: tape & reel.
  • Driver/Receiver: 1 driver and 1 receiver.
  • Operating mode: half duplex.
  • Receiver hysteresis: 100 mV.
  • Data rate: 500kbps.
  • Voltage supply range: 4.75V to 5.25V.
  • Package: surface mount package of 8-SOIC (0.154", 3.90mm width).
  • Suitable for: various communication and interface applications.
